特點：可靠性高、經久耐用：倉門不卡料，粉料輸送更通暢，效率更高。計量精確穩定：水，外加劑可采用雙速粗精設計，閥控?cái)嗔蠌氐祝ＷC混凝土高質量。操作系統智能化，操作簡單化：具有手動和全自動兩種控制方式，隨時切換。綠色環保，人性化設計：可以多種形式布置，可以提供一站多機、一站雙控等個性化服務
產品參數
項目ITEMS | UNITS | CBP120S | |
理論生產率 | Theoretical Productivity | m3/h | 120 |
攪拌主機型號 | Mixer model | / | JS2000 |
攪拌電機功率 | Motor power | kW | 2×37 |
攪拌主機公稱容量 | Nominal capacity of mixer | L | 3000 |
自動循環周期 | Automatic Cycle Period | S | 60 |
骨料顆粒（碎石/卵石） | Max.aggregate size(crushed stone / pebble) | mm | 60/80 |
骨料倉容量 | Aggregate bin capacity | m3 | 4×20 |
骨料種類 | Type of aggregate | / | 4 |
骨料稱量范圍及精度 | Weighing range and accuracy of aggregate | kg | （1666~5000）±2% |
水泥稱量范圍及精度 | Weighing range and accuracy of cement | kg | （400~1200）±1% |
水稱量范圍及精度 | Weighing range and accuracy of water | kg | （200~600）±1% |
外加劑稱量范圍精度 | Weighing range and accuracy of additive | kg | 2×（20~60）±1% |
整機功率（不含筒倉及螺旋） | Total power(Without silo & screw conveyor) | kW | 130 |
